100G OpenZR+ QSFP-DD product family is designed based on dual polarization quadrature phase shift keying (DP-QPSK), supporting extended C-band, polarization diversity coherent detection and advanced electronic link equalization. The product supports 100Gbps transmission speeds in an industry-standard, pluggable QSFP-DD form factor with 7nm DSP and can be widely used in metro carrier, access and Cloud/DCI applications

Frequency Synthesizer, Fractional-N, 2.7 to 3.45 V, 13 GHz, -40 to 125 °C, LFCSP-EP-24

200G QSFP56-DD ER4 transceivers are based on EML platform. These products feature eight channels of 25G PAM4 electrical signals and four channels of 50G PAM4 optical signals, a duplex LC connector, a APD receiver, a distance of up to 40km reach via single-mode fiber, a case temperature range of 0°C~70°C, and compliance with IEEE 802.3bs, and QSFP-DD MSA standards. The products are mainly used in 200G Ethernet, data center, and enterprise networking

85V high speed (100V/µs) to power (400µA) ratio precision op-amp in small package

400G-SR8 OSFP56 based on VCSEL, 8 channels of 50G-PAM4 electrical and optical parallel lanes,single optical port of MPO-16, up to 70m reach via OM3 multimode fiber and 100m reach reach via OM4 multimode fiber,case temperature range of 0℃-70℃, comply with IEEE 802.3bs and OSFP MSA. Products are mainly used in 400G Ethernet, data centers and cloud networks.

400G-DR4 QSFP56-DD based on EML, 8 channels of 50G-PAM4 electrical and 4 channels of 100G-PAM4 optical parallel lanes,Single optical port of MPO12, 500m maximum reach via single mode fiber,case temperature range of 0℃-70℃, comply with IEE802.3bs and QSFP-DD MSA standards, and support CMIS. Products are mainly used in 400G Ethernet, data centers and cloud networks
